LIQUID RING ( WET TYPE ) VACUUM PUMPS


Positive displacement pumps liquid ring vacuum pumps belong to the classes. Wing cavity expansion and contraction principle by taking advantage of the gas rotating liquid ring with the help of soak and drain. The ring liquid for the formation of a suitable liquid ( usually water ) when selected, the movement of gases and vapours of almost every type can be achieved. The ultimate suction pressure is usually a liquid ring vacuum pump, liquid ring is limited by the evaporation pressure. The water temperature is 15 C at the exit of the pump service, while 25 mmHg (33 mbar) vacuum pressure is reached. Liquid ring vacuum pumps in the industry has a very wide application area. Since the fluid within the working environment, filtration, drying, cooling and distillation is ideal for applications that contain moisture such as they are.


LIQUID RING ( WET TYPE ) VACUUM PUMPS
sulu-vakum-pompası

sulu-tip-vakum-pompası

vakum-pompası

vakumla-taşıma-sistemleri
gücüm-pompa

vakum-tankı-ile-vakum-pompası

vakum-ünitesi


eskişehir-vakum-pompası


LIQUID RING ( WET TYPE ) VACUUM PUMPS AREAS OF USE

Production and refining of vegetable oil deodorization process
Milk, yoghurt and fruit juice in the production of
In a sugar refinery
Agricultural products, in the production of starch
In the production of cigarettes and liquor
Removal of the internal organs of poultry
In the production of detergent and soap
Vacuum to form in the plastics industry,giving

On vacuum filters in the mining industry

Plastic pipe and profile production
Plastic coating of the cables
Yarn and fabric fixing in a reactor
For drying of textiles
Taking the air in the sludge presses that are used in tile and brick industry
Glass, ceramic and porcelain form a vacuum in the industry giving
Autoclave for sterilization process in hospitals
Central vacuum units

Vacuum drying of paste paper and paint





In the vacuum of the turbine condenser in a power plant

In the manufacture of egg trays

Drying in a vacuum to the skin

In the impregnation process in the forest industry

Pulling up to the pumps of underground water centrifugal

In vacuum lifting and carrying
